Zebra DS6878 - OCR Bright Illumination

To Next Page

To Previous Page

OCR Programming 14 - 15

OCR Bright Illumination

Parameter # 701

When enabled, image contrast is improved for OCR scanning. Zebra recommends enabling this when the

OCR string is longer than 20 characters, and for applications with busy backgrounds such as passport, check,

or VISA reading.

Enable OCR Bright Illumination

(1)

*Disable OCR Bright Illumination

(0)

NOTE Enabling OCR Bright Illumination causes the aiming pattern to blink due to the lower frame rate setting.
