15 - 82 DS6878 Product Reference Guide

2D Symbologies

Enable/Disable PDF417

Parameter # 15

To enable or disable PDF417, scan the appropriate bar code below.

Enable/Disable MicroPDF417

Parameter # 227

To enable or disable MicroPDF417, scan the appropriate bar code below.

*Enable PDF417

(1)

Disable PDF417

(0)

Enable MicroPDF417

(1)

*Disable MicroPDF417

(0)
