Imaging Preferences 6 - 13

Image File Format Selector

Parameter # 304

Select an image format appropriate for the system (BMP, TIFF, or JPEG). The digital scanner stores captured

images in the selected format.

BMP File Format

(3)

*JPEG File Format

(1)

TIFF File Format

(4)
