1 - 4 DS6878 Product Reference Guide

CR0078-S/CR0008-S Series Cradle

Figure 1-3

CR0078-S/CR0008-S Series Cradle Front View

Pairing

Bar Code

Latch

Charging/

Communications

Contacts

Charging LED

Convertible

Mount Hook
