Zebra DS6878 - GS1 Data Matrix; Maxicode

To Next Page

To Previous Page

Symbologies 15 - 85

GS1 Data Matrix

Parameter # 1336

To enable or disable GS1 Data Matrix, scan the appropriate bar code below.

Maxicode

Parameter # 294

To enable or disable Maxicode, scan the appropriate bar code below.

Enable GS1 Data Matrix

(1)

*Disable GS1 Data Matrix

(0)

Enable Maxicode

(1)

*Disable Maxicode

(0)
