Page #45 background imageLoading...
Page #45 background image
Scanning 2 - 3
LED Definitions
In addition to beeper sequences, the digital scanner communicates with the user using a two-color LED
display. Table 2-2 defines LED colors that display during scanning.
Host Specific
USB only
Four high beeps Digital scanner has not completed initialization. Wait several
seconds and scan again.
Digital scanner gives a power-up beep after
scanning a USB Device Type.
Communication with the bus must be established before the digital
scanner can operate at the highest power level.
This power-up beep occurs more than once. The USB bus may put the digital scanner in a state where power to
the digital scanner is cycled on and off more than once. This is
normal and usually happens when the host PC cold boots.
RS-232 only
High beep A <BEL> character is received and Beep on <BEL> is enabled
(Point-to-Point mode only).
Table 2-1
Standard Beeper Definitions (Continued)
Beeper Sequence Indication
Table 2-2
Scanner LED Definitions with CR0078-S Cradle
LED Indication
Scanning
Green Flash A bar code was successfully decoded.
Red Solid Transmission error or digital scanner malfunction.
Charging
Green - Slow Continuous Flash Non-critical battery temperature fault. Battery is above or below normal
operating temperature.
If this occurs, do not use the digital scanner and move the digital scanner to a
location within normal operating temperature. The digital scanner can remain in
the cradle while the battery warms or cools to normal operating temperature.
Note: For appropriate charging temperatures, see
Table 3-3 on page 3-10
.
Green - Fast Continuous Flash Digital scanner is charging.
Green Solid Digital scanner is fully charged.
Red Solid Scanner is in pre-charge, charge error or communications error with cradle.
Amber Flash Critical battery temperature fault. Battery is above or below normal operating
temperature.
If this occurs, do not use the digital scanner and move the digital scanner to a
location within normal operating temperature. The digital scanner can remain in
the cradle while the battery warms or cools to normal operating temperature.
Note: For appropriate charging temperatures, see
Table 3-3 on page 3-10
.

Table of Contents

Other manuals for Zebra DS6878

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra DS6878 and is the answer not in the manual?

Zebra DS6878 Specifications

General IconGeneral
Wavelength655 nm
Scanner type2D
Yaw reading angle-60 - 60 °
Decoding standards1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle-360 - 360 °
Input voltage5 V
BluetoothYes
Dimensions (WxDxH)69 x 97 x 185 mm
CertificationFCC, RoHS
Product colorBlack
International Protection (IP) codeIP43
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Weight238 g
