Zebra DS6878 - Matrix 2 of 5; Enable;Disable Matrix 2 of 5

To Next Page

To Previous Page

Symbologies 15 - 63

Matrix 2 of 5

Enable/Disable Matrix 2 of 5

Parameter # 618

To enable or disable Matrix 2 of 5, scan the appropriate bar code below.

Enable Matrix 2 of 5

(1)

*Disable Matrix 2 of 5

(0)
