Mobile Phone/Display Mode

Parameter # 716

This mode improves bar code reading performance off mobile phones and electronic displays. Enable this in

hand-held, hands-free, or both modes, or disable this mode.

*Disable Mobile Phone/Display Mode

(0)

Enable in Hand-held Mode

(1))

Enable in Hands-free Mode

(2)

Enable in Both Modes

(3)
