15 - 38 DS6878 Product Reference Guide

Code 39 Reduced Quiet Zone

Parameter # 1209

Scan one of the following bar codes to enable or disable decoding Code 39 bar codes with reduced quiet

zones. If you select Enable, select a 1D Quiet Zone Level on page 15-93.

Enable Code 39 Reduced Quiet Zone

(1)

*Disable Code 39 Reduced Quiet Zone

(0)
