Scanner Emulation Interface 12 - 5
Parameter Pass-Through
The Scanner Emulation host can process parameter bar code messages and send them to the attached
decoder. In this way, customers using Symbol compliant decoders can control the behavior of the entire
system by scanning the necessary parameters only once.
For example, to enable D 2 of 5, scan the D 2 of 5 Enable parameter bar code. The digital scanner and the
attached decoder both process the parameter.
*Parameter Process and Pass-Through
Parameter Process Only

Table of Contents

Other manuals for Zebra DS6878

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra DS6878 and is the answer not in the manual?

Zebra DS6878 Specifications

General IconGeneral
Wavelength655 nm
Scanner type2D
Yaw reading angle-60 - 60 °
Decoding standards1D, 2D, PDF417, PDF417, microPDF417, Composite Codes (CC-A, CC-B, CC-C), U.S. Postnet and Planet, U.K., Japan, Australian, Netherlands KIX code, Royal Mail 4 State Customer, UPU ICS 4 State Postal, USPS 4CB, TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse and Micro)
Tilt reading angle-360 - 360 °
Input voltage5 V
BluetoothYes
Dimensions (WxDxH)69 x 97 x 185 mm
CertificationFCC, RoHS
Product colorBlack
International Protection (IP) codeIP43
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Weight238 g
