Getting Started 1 - 5

Figure 1-4

CR0078-S/CR0008-S Series Cradle Back View

Rubber Foot Rubber Foot

Mounting Hole

Host Cable Groove

Rubber Foot

Power Port

Host Port

Power Cable Groove

Desk/Wall Mount

Converter Knob

Mounting Hole

Power Cable Hook

Host Cable Hook
