USB Interface 7 - 27

5018 F18

5019 F19

5020 F20

5021 F21

5022 F22

5023 F23

5024 F24

Table 7-6

USB Numeric Keypad Character Set

Numeric Keypad Keystroke

6042 *

6043 +

6044 undefined

6045 -

6046 .

6047 /

6048 0

6049 1

6050 2

6051 3

6052 4

6053 5

6054 6

6055 7

6056 8

6057 9

6058 Enter

6059 Num Lock

Table 7-5

USB F Key Character Set (Continued)

F Keys Keystroke
