Symbologies 15 - 13

Decode UPC/EAN/JAN Supplementals (continued)

Decode UPC/EAN/JAN Only With Supplementals

(1)

*Ignore Supplementals

(0)

Autodiscriminate UPC/EAN/JAN Supplementals

(2)

Enable 378/379 Supplemental Mode

(4)

Enable 978/979 Supplemental Mode

(5)

Enable 977 Supplemental Mode

(7)
