Zebra DS6878 - Page 415

To Next Page

To Previous Page

Driver’s License Set Up (DS6878-DL) 17 - 19

Date Format (continued)

No Separator

Scan this bar code immediately following a date format bar code to use no separator character between the

date fields.

YYMMDD

YYDDMM

MMDDYY

MMYYDD

DDMMYY

DDYYMM

No Separator
