4 - 12 DS6878 Product Reference Guide

HID Country Keyboard Types (continued)

Spanish Windows

Italian Windows

Swedish Windows

UK English Windows

Japanese Windows

French Canadian Windows 2000/XP

Portuguese/Brazilian Windows
