GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 7, Page 12
PARALLEL PORT MODE
Option 4 of the Data Mode Main Menu enables or disables the parallel port for transferring cache
data to a printer. The current port status is displayed above the Data Mode Main Menu:
Parallel Port Disabled
NOTE: Before the parallel port can be enabled the GDP-32
II
must be connected to an on-line
printer via the parallel port.
1. Connect the GDP-32
II
parallel port to the printer using a Zonge Parallel Cable.
2. Turn the printer on.
3. Press from the Data Mode Main Menu to enable the parallel port.
4. The receiver returns to the Data Mode Main Menu and displays the current port
status:
Parallel Port Enabled: ready
5. See Section 7.6 for complete instructions on transferring data. When data transfer is
complete, disable the parallel port.
