19.3 NT-32 TRANSMITTER SYSTEM
Setup of the NanoTEM system using the NT-32 transmitter is similar to the steps used when
using all of the other Zonge Transmitter systems.
Menu 1
Configuration information is entered into
Menu 1 in the GDP-32
II
data program as
outlined in Section 12.5. Of particular
importance is the Transmitter Type, which
should be set to NT-32.
Menu 2
After initializing the NT-32 Transmitter,
the data collection program continues on to
Menu 2 allowing entry of record keeping
information such as line number, operator
name, etc. A-Spacing (
A-SP) is displayed
in this menu, but it is not used for
NanoTEM.
NANOTEM 0610 15 Mar 98 08:53:40
Program: NanoTEM Sample Rate: 1.2usec
Array type: In-loop
Duty cycle: 50% Window: Zonge Standard
Receiver moment: 250
Transmitter X, Y: 20 20 Turns: 1
Tx Delay 1.5 Antenna Delay 2
Transmitter Type NT-32
Robust Filter: None
Gain Mode: Standard Units:Meters
Alias : IN
CONTINUE: Next menu, ESCAPE: Prev. menu
Data
NANOTEM 0610 15 Mar 98 08:53:45
OPER JOHN.DOE TX ID 1 A-SP 100
JOB 94001 LINE 1 N SPREAD 1
CONTINUE: Next menu, ESCAPE: Prev. menu
