Zonge GDP-32 - TEM Program Operation

GDP-32
II
INSTRUCTION MANUAL
October 2002 Section 12, Page 4
12.3 TEM PROGRAM OPERATION
MENU 1:
In all of the following menu descriptions, the bold fields in the boxes are the parameters that can
be changed by the operator.
Display screen with regular analog cards
installed:
Display screen with both regular analog
cards and NanoTEM cards installed:
TEM 0539 15 Mar 98 08:53:40
Array type: In-loop
Duty cycle: 50% Window: Zonge Standard
Receiver moment: 10000
Transmitter X, Y: 1 1 Turns: 1
Tx Delay 50 Antenna Delay 15
Transmitter Type GGT Series
Robust Filter: none
Gain Mode: Standard Units:Meters
Alias : IN
CONTINUE: Next menu, ESCAPE: Prev. menu
Data
TEM 0539 15 Mar 98 08:53:40
Program: NanoTEM Sample Rate: 1.2usec
Array type: In-loop
Duty cycle: 50% Window: Zonge Standard
Receiver moment: 250
Transmitter X, Y: 20 20 Turns: 1
Tx Delay 1.5 Antenna Delay 2
Transmitter Type ZT-20
Robust Filter: None
Gain Mode: Standard Units:Meters
Alias : IN
CONTINUE: Next menu, ESCAPE: Prev. menu
Data
