Zonge GDP-32 - Nanotem Sample Data

FAST TRANSIENT ELECTROMAGNETICS PROGRAM
Section 19, Page 13 October 2002
19.7 NANOTEM SAMPLE DATA
The above data were acquired using a dummy load on an NT-20 transmitter.
0778
NANO0534 94-12-31 17:58:13 11.7v INL
OPER SAU TX ID T-21 A-SP 1
JOB 94118 LINE 4 N SPREAD 1
50% RxM 10000 TxX 1 TxY 1 #T 1 Ref 0.113
Tx Delay 1.5 Antenna Delay 2 Alias IN
Robust None
1 LoPass Notch+60,3-5,9 S/N 117 Passed 1.00014
2 LoPass Notch+60,3-5,9 S/N 114 Passed 0.99794
3 NanoTem A/D 14-bit S/N 2 Passed 1.00000
Front Panel S/N 21, Cal S/N 15, Temp 20.0, Humidity 51.4, EPROM ZMT-32 Z201s
0779
NANO0534 94-12-31 18:00:05 11.6v INL
Tx 1 Rx 3 N OUT
32 Hz 512 Cyc Tx Curr 1 4.819u 1u 1.606u
3 Hz 3 59.005u 80.23u 12.97 040O 14.61u 0.00 0
Wn Mag 3 Rho 3
0.319u 19.863m 2692.5
1.925u 4.8605m 343.38
3.531u 2.8371m 178.83
5.137u 2.0226m 119.96
6.743u 1.4475m 95.275
8.350u 1.1190m 79.222
10.73u 900.31u 60.311
13.95u 611.69u 50.388
17.16u 499.88u 40.790
21.14u 391.33u 33.942
25.97u 294.99u 29.080
32.28u 221.91u 24.461
41.08u 162.99u 20.108
51.49u 118.19u 17.097
64.24u 86.311u 14.580
80.23u 59.005u 12.974
100.9u 51.056u 9.7527
128.0u 38.916u 7.8601
161.6u 30.188u 6.3142
203.1u 22.741u 5.2111
255.0u 20.282u 3.8488
321.0u 18.985u 2.7393
404.9u 14.122u 2.2663
508.7u 12.730u 1.6603
639.4u 8.2726u 1.5116
805.4u 6.1923u 1.2482
1.014m 4.9634u 0.9859
1.276m 3.1665u 0.9065
1.607m 2.7103u 0.6845
2.022m 0.9478u 0.9404
2.547m 0.1911u 1.8622
N
anoTEM Channel 3
