RPIP PROGRAM
Section 8, Page 7 January 2003
8.3 DATA COLLECTION
Begin collecting data after setting up the receiver for an RPIP field survey. For complete
information on receiver setup see Section 6. To begin, press
Enter
from the Data Acquisition
Screen.
DATA COLLECTION EXAMPLE
The following example displays the screens and results of an RPIP Dipole - Dipole Field Survey.
For this example the field parameters are set as follows:
Initial Program Screen
Survey type Non-Reference RPIP
Array type Dipole - Dipole
Gain Mode Noisy (default)
Units Meters (default)
Moving Average filter Enabled (default)
Operator Information Screen
OPER SMITH
TX ID 1234
A-SP 6.0
JOB 94001
LINE 1 N (default)
SPREAD 1 (default)
Channel Parameters Screen
CH N
1 ON 1
2 ON 2
3 OFF
4 OFF
Data Acquisition Screen
Frequency 0.125 Hz
Cycles 4
TX Curr 1 (default)
To Next Page
