RPIP PROGRAM
Section 8, Page 5 January 2003
SCREEN 2 - OPERATOR INFORMATION SCREEN
Select a parameter or fill in the appropriate
information for each of the user
programmable fields as described in
Section 5 ā Accessing Programs. If
GRADIENT array is selected, the Y-
coordinate of the transmitter dipole (Ay)
will be displayed in place of the line
designator.
SCREEN 3 - CHANNEL PARAMETERS SCREEN
Set the channels displayed to ON, OFF or
Ref as needed. For more information
refer to Section 5 ā Accessing Programs.
0192 RPIP0613 11.7 08 Jan 18 10:17:44
OPER dbf TX ID 1234 A-SP 6.0
JOB 1 LINE 1 N SPREAD 1
CONTINUE:Next Menu, ESCAPE: Prev Menu
0192 RPIP0613 11.7 08 Jan 18 10:17:44
OPER dbf TX ID 1234 A-SP 6.0
JOB 1 LINE 1 N SPREAD 1
CH N
1 ON 1
2 ON 2
3 OFF
4 OFF
Enter channel parameters
Ch Info
To Next Page
