Zonge GDP-32 - Receiver Setup

GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 9, Page 20
RECEIVER SETUP
Geophysical Data Processor
GDP-32
II
ANALOG I/O
CASE GND, COM
Porous Pot
Electrode
PPE/1
Reference
Electrode
Side panel
GDP-32
Signal Input through
IO 32/8 meter/connection
panel
Wires from BR12W
or BR12WR
Porous Pot
Electrodes
PPE / 1
Receiver Setup for Resistivity, Time Domain IP,
Resistivity / Phase IP, and Non-Reference Complex Resistivity
