Zonge GDP-32 - TEM Window Centers for Zero Delay

TRANSIENT ELECTROMAGNETICS PROGRAM
Section 12, Page 19 October 2002
12.8 TEM WINDOW CENTERS FOR ZERO DELAY
Window center times saved in the cache during data acquisition will be the above values plus the
delay after turnoff. See Section 12.10 for sample data blocks.
WINDOW 32, 16, 8 2 1 .5 .25 .125 .0625
#'S and 4 Hz Hz Hz Hz Hz Hz Hz
1 0.0 µs 0.0 µs 0.0 µs 0.0 µs 0.0 µs0.0ms0.0ms
2 30.5 61.0 122.0 244.1 488.3 976.6 1.953
3 61.0 122.1 244.1 488.3 976.6 1.953 3.906
491.6 183.1 366.2 732.4 1.465ms2.930 5.859
5 122.1 244.1 488.3 976.6 1.953 3.906 7.813
6152.6 305.2 610.4 1.221ms2.441 4.883 9.766
7 197.8 395.6 791.1 1.582 3.164 6.329 12.66
8259.0 517.9 1.036ms2.072 4.143 8.287 16.57
9 320.1 640.2 1.280 2.561 5.121 10.24 20.48
10 395.6 791.1 1.582 3.164 6.329 12.66 25.32
11 487.3 974.7 1.949 3.899 7.797 15.59 31.19
12 607.3 1.215 ms 2.429 4.858 9.717 19.43 38.87
13 774.5 1.549 3.098 6.196 12.39 24.78 49.57
14 972.3 1.945 3.889 7.778 15.56 31.11 62.23
15 1.215 ms 2.429 4.858 9.717 19.43 38.87 77.73
16 1.518 3.037 6.073 12.15 24.29 48.58 97.17
17 1.911 3.821 7.643 15.29 30.57 61.14 122.3
18 2.426 4.852 9.704 19.41 38.82 77.63 155.3
19 3.064 6.128 12.26 24.51 49.02 98.05 196.1
20 3.852 7.704 15.41 30.82 61.63 123.3 246.5
21 4.838 9.676 19.35 38.71 77.41 154.8 309.6
22 6.094 12.19 24.38 48.75 97.50 195.0 390.0
23 7.687 15.37 30.75 61.50 123.0 246.0 492.0
24 9.659 19.32 38.64 77.28 154.6 309.1 618.2
25 12.14 24.29 48.57 97.15 194.3 388.6 777.2
26 15.30 30.59 61.18 122.4 244.7 489.5 978.9
27 19.25 38.51 77.02 154.0 308.1 616.1 1232.3
28 24.24 48.48 96.96 193.9 387.8 775.6 1551.3
29 30.53 61.06 122.1 244.2 488.5 977.0 1954.0
30 38.42 76.83 153.7 307.3 614.7 1229.3 2458.6
31 48.38 96.76 193.5 387.1 774.1 1548.2 3096.4
For 32 Hz we
g
et 22 windows for 50% dut
y
c
y
cle
25 windows for 16 Hz
28 windows for 8 Hz
31 windows for 4 Hz and belo
w
