GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 9, Page 8
9.3 DATA COLLECTION
After setting up the receiver for a TDIP Field Survey, press
Enter
from the Data Acquisition
Screen to begin collecting data. For complete information on receiver setup see Section 6.
DATA COLLECTION EXAMPLE
The following example displays the screens and results of a TDIP Dipole - Dipole Field Survey.
For this example the field parameters are set as follows:
Initial Program Screen
Survey type Dipole - Dipole
Mode Synchronous
Gain Mode Noisy (default)
Units Meters (default)
Environment Type Quiet (default
Moving Average filter Enabled (default)
Operator Information Screen
OPER SMITH
TX ID 1
A-SP 100
JOB 94001
LINE 1 N (default)
SPREAD 1 (default)
Channel Parameters Screen
CH N
1 ON 1
2 ON 2
3 OFF
Data Acquisition Screen
Frequency 0.125 Hz
Cycles 4
TX Curr 1
