Zonge GDP-32 - Nanotem Field Setup; Field Setup

TRANSIENT ELECTROMAGNETICS PROGRAM
Section 12, Page 49 October 2002
12.26 NANOTEM FIELD SETUP
NT-20 FIELD SETUP
CALIBRATOR
ANALOG I/O
INPUT
CHANNELS 1-6
CAL+ CAL- COM
CASE
GND
+
+
++++
+
_
__
____
CH5 CH6
Red
Black
CH1 CH2 CH3 CH4
II
GDP-32
Center
tap
Top view of plug
2 - 1K ohm
resistors in
series with
center tap
NT-20
NT ZT
Red
Black
Blue
Black
NANOTEM ZEROTEM
+
-
SET MODE
Receiver Loop
Transmitter Loop
to 12V battery
to Transmitter I/O
on GDP
150 ohm
resistor
NT SETUP - GDP-32
Use this hookup for proper
polarity.
Date: 05-30-01
