QUICK START
Section 4, Page 5 October 2003
4.3 ENTER SURVEY PARAMETERS
Each Field Survey Program has four primary screens where survey parameters are entered.
1. Initial Program Screen
Enter the Array type, Mode, etc. (depending upon survey type), and press
Enter
.
2. Operation Information Screen
This screen displays semi-permanent data. Enter the value for OPERATOR, TX ID
(Transmitter ID), A-SP (A-Spacing or Dipole Spacing), JOB, LINE, SPREAD (as
needed) and press
Enter
.
3. Channel Parameters Screen
Enter channel parameters. Some examples are:
NOTE: Refer to the appropriate Survey Program chapters for more information on
setting up channels.
Any designator other than OFF will turn on channels for all programs.
For CR, Ref is the current reference channel and can be set to any single channel.
Any designator other than Ref can be used for the rest of the channels.
For CSAMT and HACSAMT, the program uses the first orthogonal H-field
component found for the respective E-field. Hence, Ex must always precede Hy;
Ey precedes Hx, etc., as above.
TDIP RPIP CR AMT,CSAMT TEM
Ch N Ch N Ch N Ch Sta/Ant Ch Sta/Ant Ch Sta/Ant Ch ANT
1 ON 1 1 ON 1 1 Ref 0 1 Ex 1 1 Ex 1 1 Ex 1 1 Hx 43
2 ON 2 2 ON 2 2 Ex 1 2 Hy 211 2 Ex 2 2 Hy 211 2 Hy 53
3 ON 3 3 ON 3 3 Ex 2 3 Ey 2 3 Ex 3 3 Ey 1 3 Hz 63
4 ON 4 4 ON 4 4 Ex 3 4 Hx 212 4 Ex 4 4 Hx 212 4 OFF
5 ON 5 5 ON 5 5 Ex 4 5 Hz 30 5 Ex 5 5 Ex 2 5 OFF
6 ON 6 6 ON 6 6 Ex 5 6 OFF 6 Ex 6 6 Hy 321 6 OFF
7 OFF 7 OFF 7 Ex 6 7 OFF 7 Ex 7 7 Ey 2 7 OFF
8 OFF 8 OFF 8 OFF 8 OFF 8 Hy 211 8 Hx 322 8 OFF
N=1,6 IP 1-STATION 7-STATION 2-STATION 1-STATION
TENSOR
SCALAR
VECTOR
3
-
AXIS
