CONTROLLED-SOURCE AUDIO FREQUENCY MAGNETOTELLURICS
Section 11, Page 23 May 2002
11.12 FIELD CONFIGURATIONS
RECONNAISSANCE CSAMT SETUP
Geophysical Data Processor
GDP-32
ANALOG I/O
CASE GND, COM
Porous Pot
Electrode
PPE/1
Reference
Electrode
Side panel
GDP-32
Signal Input through
IO 32/8 meter/connection
panel
Wires from BR12W
or BR12WR
Porous Pot
Electrodes
PPE / 1
Reconnaissance CSAMT Setup with Six Electric Field Dipoles
and One Magnetic Field Sensor
ANT-1
A
N
T/
2
-
O
T
Shield connected to Case GND
II
To Next Page
