Zonge GDP-32 - Sample Data Blocks

GDP-32
II
INSTRUCTION MANUAL
January 2003 Section 10, Page 18
10.7 SAMPLE DATA BLOCKS
SHOWING DIFFERENCE BETWEEN REFERENCE AND
NON-REFERENCE (HARMONIC RP/IP) OPERATION
Dipole-Dipole array used
0005
CR 0535 98-11-03 14:44:02 12.6v D-D Card status:Passed or Failed QC test
OPER 1 TX ID 1 A-SP 100 Sh 0.100
JOB 89001 LINE 1.0 N SPREAD 1 Gain factors for each card
1 DiffAmp Notch+60,3-50,3 S/N 185 Passed 1.00192
2 DiffAmp Notch+60,3-50,3 S/N 177 Passed 0.99835
3 DiffAmp Notch+60,3-50,3 S/N 61 Passed 0.99921
4 DiffAmp Notch+60,3-50,3 S/N 57 Passed 1.00329
5 DiffAmp Notch+60,3-50,3 S/N 60 Passed 0.99876
6 DiffAmp Notch+60,3-50,3 S/N 66 Passed 0.99586
modification level indicator SEM's in mr
0006
CR 0528 98-11-03 14:45:31 12.7v D-D SP in millivolts
Tx 1 Rx 3 N OUT
.125 Hz 4 Cyc Tx Curr 1.00 Contact resistance in ohms
1 Ex 1 268.00m -2.4 396.8 030O .11 2.96 1.23K
2 Ex 2 268.62m -2.4 1.591K 030O .11 0.12 690.1
3 Ex 3 268.48m -2.4 3.975K 030O .11 -0.56 1.02K
4 Ex 4 268.28m -2.4 7.943K 030O .11 -1.78 2.27K
5 Ex 5 268.13m -2.4 13.89K 030O .11 -3.56 1.17K
6 Ex 6 268.47m -2.5 22.26K 030O .11 -5.92 1.63K
Harmonics 1 3 5 7 9
1 268.00m -40.7 262.85m -119.1 253.69m -186.8 242.55m -241.6 230.60m -282.4
2 268.62m -40.8 263.46m -119.2 254.28m -186.8 243.16m -241.4 231.14m -282.5
3 268.48m -40.7 263.33m -119.0 254.19m -186.6 243.01m -241.0 231.03m -282.1
4 268.28m -40.8 263.13m -119.1 253.99m -186.8 242.83m -241.4 230.82m -282.4
5 268.13m -40.8 262.96m -119.2 253.81m -186.8 242.68m -241.4 230.70m -282.3
6 268.47m -40.8 263.32m -119.1 254.15m -186.7 243.00m -241.5 231.02m -282.6
0007
CR 0535 98-11-03 14:51:17 12.6v D-D
Tx 1 Rx 3 N OUT
.125 Hz 5 Cyc Tx Curr 2.10
1 Re 268.04m -40.9 188.9 030O .03 0.23 .000u
2 Ex 1 268.64m .0 188.9 030O .02 2.96 1.23K
3 Ex 2 268.49m .1 755.3 030O .01 0.12 690.1
4 Ex 3 268.29m -.0 1.887K 030O .02 -0.56 1.02K
5 Ex 4 268.15m -.1 3.771K 030O .02 -1.78 2.27K
6 Ex 5 268.50m -.0 6.609K 030O .02 -3.56 1.17K
7 Ex 6 268.21m -.1 10.56K 030O .02 -5.92 1.63K
Harmonics 1 3 5 7 9
1 1.0000 -40.9 980.89m -118.9 946.80m -186.8 904.33m -241.7 860.34m -282.6
2 268.64m .0 268.64m .0 268.66m -.1 268.75m -.1 268.66m .1
3 268.49m -.00 268.51m -.1 268.54m -.3 268.59m -.4 268.56m -.3
4 268.29m .0 268.30m .0 268.33m -.1 268.38m -.1 268.27m .0
5 268.15m -.00 268.15m .1 268.14m -.00 268.19m -.1 268.14m -.0
6 268.50m .0 268.51m .0 268.52m -.1 268.57m -.0 268.53m .1
7 268.21m .0 268.17m .1 268.07m .0 268.05m -.1 267.82m .1
