GDP-32
II
INSTRUCTION MANUAL
October 2003 Section 4, Page 6
For CSAMT the numbers beside the H-field designators in the Sta/Ant column
are coil serial numbers for coil calibrations. The last digit signifies the antenna
type:
A single channel ANT/1 CSAMT antenna ends in 0.
A dual channel ANT/2 ends in 1 for channel 1 or 2 for channel 2.
CSAMT / AMT antennas, ANT/3 ends in 3.
A TEM/ 3 TEM antenna ends in 9.
An MT/AMT antenna using Sarloos coils or equivalent ends in 4 for DC to 1 kHz
range or 3 for .1 to 10,000 Hz range.
Numbers beside the E-field designators in the Sta/Ant column are used as
station numbers.
Press
Enter
to go to the next screen.
4. Data Acquisition Screen
Select frequency, number of cycles to average, notch filter in or out, etc. From here
you can perform Calibrations, System Checks or set Gains prior to acquiring data.
