TRANSIENT ELECTROMAGNETICS PROGRAM
Section 12, Page 21 October 2002
12.10 SAMPLE DATA BLOCKS
0094
TEM 0539 98-03-15 08:57:47 12.3v INL
OPER JOHN DOE TX ID 1 A-SP 100
JOB 94001 LINE 1 N SPREAD 1
50% RxM 10000 TxX 1 TxY 1 #T 1 Ref 0.113
Tx Delay 50 Antenna Delay 15 Alias IN
Robust None
1 LoPass Notch+60,3-5,9 S/N 91 Passed 0.99382
2 LoPass Notch+60,3-5,9 S/N 81 Passed 0.99478
3 LoPass Notch+60,3-5,9 S/N 82 Passed 0.99368
4 LoPass Notch+60,3-5,9 S/N 89 Passed 0.99341
5 LoPass Notch+60,3-5,9 S/N 94 Passed 0.99094
6 LoPass Notch+60,3-5,9 S/N 95 Passed 1.00041
7 LoPass Notch+60,3-5,9 S/N 93 Passed 0.99464
8 LoPass Notch+60,3-5,9 S/N 96 Passed 0.99739
Front Panel S/N 21, Cal S/N 13, Temp 27.1, Humidity 38.9, EPROM ZMT-32 Z201f
0095
TEM 0539 98-03-15 08:57:49 12.3v INL
Tx 1 Rx 3 N OUT
32 Hz 1024 Cyc Tx Curr 1 122.1u 26u 30.50u
1 Hz 1 2.0731u 1.549m 0.871 060O 0.018u 3.24 287
2 Hy 2 1.9526u 1.549m 0 060O 0.016u 4.09 240
3 Hx 3 1.7403u 1.549m 0 060O 0.018u 2.78 256
Wn Mag 1 Mag 2 Mag 3 Rho 1
31.07u 38.861m 39.013m 38.965m 0.8543
61.59u 21.049m 21.132m 21.106m 0.4072
92.11u 11.412m 11.456m 11.444m 0.3121
122.6u 6.1950m 6.2196m 6.2136m 0.2907
153.1u 3.3703m 3.3835m 3.3809m 0.3009
183.6u 1.8385m 1.8463m 1.8452m 0.3327
228.9u 782.51u 786.10u 786.43u 0.4072
290.0u 244.84u 246.25u 247.21u 0.5951
351.2u 84.190u 84.299u 85.328u 0.8812
426.7u 30.488u 30.635u 31.588u 1.2534
518.4u 14.444u 14.669u 15.164u 1.4902
638.4u 9.0692u 9.0316u 9.4358u 1.4362
805.6u 6.2024u 6.2712u 6.2056u 1.2554
1.003m 4.1632u 4.3886u 3.9539u 1.1355
1.246m 3.2232u 2.9787u 2.7866u 0.9390
1.549m 2.0731u 1.9526u 1.7403u 0.8710
1.942m 1.4938u 1.3632u 1.0208u 0.7480
2.457m 0.9400u 0.8184u 0.5879u 0.6881
3.095m 0.4965u 0.4728u 0.3523u 0.7167
3.883m 0.4435u 0.3710u 0.3247u 0.5294
4.869m 0.3140u 0.2078u 0.2462u 0.4570
6.125m 0.1698u 0.1632u 0.0997u
0.4699
IN-LOOP arra
y
used
Duty Cycle
Rx Moment
Tx X & Y Lengths
# turns
Ref coil factor
Gain factors for each card
Sam
p
lin
g
Dela
y
Antialias Dela
y
Contact resistance
SP in millivolts
SEM
Apparent Resistivity (Ωm)
TEM Decay Curves
Window Center Times
The first window time (31.1 µs) is calculated
from the sum of Tx Delay (50), Antenna Delay
(15) and Antialias Delay (26). The total delay
is 91 µs. Subtract this from 122.1 (sampling
delay) to give 31.1 µs for window one.
All other window times are then offset by 30.6
µs from the values given in the table in Section
12.8.
