10.11 FIELD CONFIGURATIONS
GDP SETUP: RESISTIVITY, TDIP, RPIP, NRCR
Geophysical Data Processor
GDP-32
ANALOG I/O
CASE GND, COM
Porous Pot
Electrode
PPE/1
Reference
Electrode
Side panel
GDP-32
Signal Input through
IO 32/8 meter/connection
panel
Wires from BR12W
or BR12WR
Porous Pot
Electrodes
PPE / 1
