TRANSIENT ELECTROMAGNETICS PROGRAM
Section 12, Page 29 October 2002
HIGH-POWER TEM TRANSMITTER SETUP
Voltage
Regulator
VR-1
VR-CN/6 Cable
Transmitter
GGT-30
XMT/32 - CN/6 Cable
Motor
Generator
ZMG-30
GGT-30-PW
Cable
XMT/32 - CN/6 Cable
(optional)
Wire from BR12/W or
PR/1W with PW/1
To GDP-32
II
