Zonge GDP-32 - Complex Resistivity Receiver Setup with Current Reference

GDP-32
II
INSTRUCTION MANUAL
January 2003 Section 10, Page 30
COMPLEX RESISTIVITY RECEIVER SETUP WITH CURRENT REFERENCE
Geophysical Data Processor
GDP-32
Porous Pot
Electrode
PPE/1
Reference
Electrode
Side panel
GDP-32
Signal Input through
IO 32/8 meter / connection
panel
Wires from BR12W
or BR12WR
Porous Pot
Electrodes
PPE / 1
REF-IN
ANALOG I/O
CASE GND, COM
