Zonge GDP-32 - Gdp-32

May 2002
18. GDP-32
II
USERS NOTES
This section of the manual is provided for users to add their own field
operating notes as well as to compile notes sent out by Zonge Engineering
concerning operation of the GDP-32
II
and other ZERO equipment.
18.1 USE OF THE ATTENUATOR ............................................... 2
18.2 RECALIBRATE WHEN REPLACING ANALOG CARDS2
18.3 CONNECTING PERIPHERALS TO THE GDP-32
II
.......... 3
18.4 ALWAYS MEASURE CONTACT RESISTANCE - CRES 3
18.5 XMT-32 TRANSMITTER CONTROLLER SPECS............ 4
GENERAL DESCRIPTION .......................................................................... 4
CONTROLS & DISPLAYS .......................................................................... 4
OUTPUTS & INPUTS................................................................................... 4
FUNCTIONS ................................................................................................. 4
18.6 TRANSMITTER CONTROL INTERFACE ........................ 5
18.7 RESISTANCE OF STANDARD GAUGE WIRE................. 6
18.8 SETUP INSTRUCTIONS FOR LOADBANK LB2500........7
18.9 ANTENNA DESIGNATIONS.................................................8
18.10 SERIAL PORT DATA TRANSFER, HYPERTERMINAL 9
START HYPERTERMINAL................................................................................. 9
TESTING THE GDP TO COMPUTER SETUP........................................................ 9
WRITING DATA TO A COMPUTER FILE ............................................................ 9
18.11 LOCAL AREA NETWORK (LAN) CONNECTION ........ 10
18.12 BLACK SCREEN WHEN RESETTING THE GDP-32
II
.. 10
18.13 OBSERVE PROPER TURN-OFF PROCEDURE ............. 10
