Zonge GDP-32 - Nanotem Calibrate Setup

GDP-32
II
INSTRUCTION MANUAL
October 2002 Section 12, Page 46
NT-20 NANOTEM CALIBRATE SETUP
GDP-32
II
CALIBRATOR
ANALOG I/O
INPUT
CHANNELS 1-6
CAL+ CAL- COM
CASE
GND
+
+
++++
+
_
__
____
CH5 CH6
Red
Black
CH1 CH2 CH3 CH4
Center
tap
Top view of plug
2 - 1K ohm
resistors in
series with
center tap
TransmitterReceiver
NanoTEM Cal
NT-20
NT ZT
Red
Black
Blue
Black
NANOTEM ZEROTEM
+
-
SET MODE
10 cm 
jumper cables
60 cm twisted-
pair cable
to 12V battery
to Transmitter I/O
on GDP
NT CALIBRATE - GDP-32
Use this hookup for proper
polarity.
Date: 05-30-01
II
