RPIP PROGRAM
Section 8, Page 3 January 2003
8.2 PROGRAM OPERATION
Field Survey programs operate using several parameter entry screens. Press
Enter
to move to
the next screen or
Escape
to return to the previous screen.
For a complete description of each screen and generic fields refer to Section 5 – Accessing
Programs. Field parameters specific to this Survey Program are listed below.
SCREEN 1 - INITIAL PROGRAM SCREEN
Select or enter a parameter for each user programmable field. User programmable fields unique
to RPIP are:
Survey Type
Non-reference RPIP
(Default selection) This is the
standard resistivity/phase IP
program.
Continuous
This mode is an experimental
program developed for continuous
logging in downhole electrode and
marine applications. Once started,
measurements are repeated
automatically at a user-specified
time interval, until the
Escape
key
is pressed.
Reference RPIP
Reference RPIP is a single-
frequency, complex resistivity
survey. It uses a selected channel
to monitor the transmitter current,
and then computes the system
response (i.e. the deconvolved
magnitude and the phase response)
of the measured channels with
respect to the reference channel
array type.
0192 RPIP0613 11.7 08 Jan 18 10:17:44
Survey Type: Non-reference RPIP
Array Type: Dipole-Dipole
Gain Mode: Noisy Units: Meters
Moving Average Filter: Enabled
CONTINUE:Next Menu, ESCAPE: Prev Menu
