COMPLEX RESISTIVITY & HACSAMT PROGRAM
Section 10, Page 25 January 2003
MENU 3:
The following example is the setup for a 6
E-field and 1 H-field harmonic CSAMT
survey
MENU 4
<— We have selected the harmonic
CSAMT option
<— Coil number 490
For Menus 3 and 4, the operation is just as it is for the standard CSAMT survey type. Refer to
the CSAMT program chapter for more information.
0094 CR 0535 12.3 15 Mar 98 08:57:59
Survey AMT
Tx 1 Rx 3 N OUT
1 Hz / 1 Cycle Tx Curr 1
CH Sta/Ant
1 Ex 1
2 Ex 2
3 Ex 3
4 Ex 4
5 Ex 5
6 Ex 6
7 Hy 490
8 OFF
CONT-Set gains, ESC-Prev Menu
0094 CSHA 0535 15 Mar 98 08:53:50
OPER 1 TX ID 1 A-SP 100
JOB 89001 LINE 1.0 N SPREAD 1
CH Sta/Ant
1 Ex 1
2 Ex 2
3 Ex 3
4 Ex 4
5 Ex 5
6 Ex 6
7 Hy 490
8 OFF
Enter channel parameters
VarAsp ExtAmp Ch Info
To Next Page
