GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 9, Page 16
These data were acquired using an RC network and a constant current laboratory transmitter.
The RC network is as follows:
Block 0003 is the Program Data Header. A new Program Data Header is written to the data
cache whenever the operator returns to the Operation Information Screen.
Block 0004 is the Data Block and is written to the data cache when
Enter
is pressed at the end
of each data acquisition cycle.
50 K
50 K
1 uF
To Next Page
