MENU 3:
The following example is for a single station vector setup - two E-fields and three H-fields.
The
function key is active.
CH. Any channel designator other than OFF will turn the channel ON.
Ex, Ey, Ez - Electric field designators
Hx, Hy, Hz - Magnetic field designators
NOTE: For computing the Cagniard resistivity from the E and H fields, the program
matches orthogonal pairs of fields. For this example Channels 1 and 2 will be used to
calculate RHOxy and channels 3 and 4 will be used to calculate RHOyx. Data for Hz are
acquired and put into the data cache without any calculations being done on the value,
other than removal of calibrates.
Sta/Ant. Dual usage field:
1. H-field designator: Identifies the magnetic field antenna used for that channel. The
number in this field must have an exact matching number in the antenna calibrate
cache.
2. E-field designator: Identifies the station number for multiple E-field measurements.
0097 CSAMT 0537 15 Mar 98 08:53:47
OPER JOHN.DOE TX ID Z-30 A-SP 100
JOB 94007 LINE AJO ROAD N SPREAD 1
CH Sta/Ant
1 Ex 3
2 Hy 142
3 Ey 3
4 Hx 141
5 Hz 50
6 OFF
7 OFF
8 OFF
Enter channel parameters
VarAsp ExtAmp Ch Info
To Next Page
