GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 11, Page 12
After the selected number of cycles have been acquired (or
Escape
is pressed), the final display
will be one of the following:
Display "A"
MAG. The decalibrated magnitude in volts for each E-field or kilogammas for each H-field
component measured.
φ
φφ
φ
. The decalibrated phase for each E- or H-field component measured.
0097 CSAMT 0537 12.3 15 Mar 98 09:11:15
Survey Grounded
Tx 1 Rx 3 N OUT
1 Hz 4/ 4 Cycles Tx Curr 1
CH Sta/Ant MAG
φ
φφ
φ
SEM GGGA
1Ex 3 675.4u-256.7 .13005O
2Hy 142124.8u-1789.6 .10005O
3Ey 3 702.2u-179.4 .11005O
4Hx 141223.9u-1838.9 .12005O
5Hz 50154.4u-1849.6 .11005O
6OFF
7OFF
8OFF
CONTINUE to save, RE SET to discard
PREV NEXT RHO
