Zonge GDP-32 - Page 242

GDP-32
II
INSTRUCTION MANUAL
October 2002 Section 12, Page 26
TEM RECEIVER WITH 3-AXIS (X,Y,Z) COILS
Geophysical Data Processor
GDP-32
II
Porous Pot
Electrode
PPE/1
Reference
Electrode
(optional)
Side panel
GDP-32
II
X
MT/32-CN/6
T
ransmitter Control
Cable to GGT or ZT
T
ransmitters
(optional)
H
x
H
y
H
z
Shields connected
to Analog Ground
(COM)
ANALOG I/O
