GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 16, Page 22
Figure 16.8 (b) - Large Case Battery Compartment
Batteries
B1,B2,B3,B4
Water Resistant
Gasket
BATTERY
COMPARTMENT
4 Pin
Molex
Connector
GDP-32II
MAIN CASE
BATTERY
COMPARTMENT
FOAM LID
LOWER CASE PANEL
Foam
Strip
ANALOG CARDS,
INSIDE
Space for
terminal block
TIMING CARD &
CRYSTAL, INSIDE
