GDP-32
II
INSTRUCTION MANUAL
May 2002 Section 6, Page 12
Table 6.1 - Examples of Good RPIP Calibration Values
Note: Values vary from board to board, depending upon components and filters. Magnitudes
are normalized to the magnitude at the lowest calibration frequency; phases are in milliradians.
NOTCH FILTER SELECTION
Frequency None 60/180 Hz 50/150 Hz 50/60 Hz
(Hz) Mag Phase Mag Phase Mag Phase Mag Phase
8192 .14 1370 .14 1347 .14 1347 .14 1322
4096 .40 2792 .40 2789 .40 2787 .40 2783
2048 .59 -2597 .59 -2581 .60 -2585 .60 -2570
1024 .60 -2469 .59 -2426 .60 -2434 .60 -2392
512 .82 -1557 .81 -1460 .82 -1479 .82 -1381
256 .83 -1536 .78 -1229 .81 -1327 .78 -1019
128 .86 -1389 .81 -1551 .72 -1862 .68 -2024
64 .86 -1384 .46 -508 .79 -1114 .45 -239
32 .97 -697 .95 -878 .94 -954 .93 -1136
16 1.00 -349 .99 -423 .99 -451 .99 -515
81.00-1741.00-2101.00-2181.00-254
41.00-1741.00-1921.00-1961.00-213
21.00-1811.00-1901.00-1921.00-201
11.00-1811.00-1841.00-1861.00-190
.5 1.00 -90 1.00 -92 1.00 -93 1.00 -95
.25 1.00 -90 1.00 -91 1.00 -92 1.00 -93
.125 1.00 -90 1.00 -91 1.00 -92 1.00 -92
