DD+DIS150
.06E
Repair and Service
Tools and auxiliary Means
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
Edition 1, Revision 2 CR 30-X Chapter 3.2 / 4
03-2010 Type 5175 / 100/110 Agfa Company Confidential
1 Machine specific Tools
The listing of machine specific tools is divided in required tools and
recommended tools.
Required tools: They are required for installation, repair or troubleshooting.
Recommended tools: They may facilitate installation, repair or troubleshooting.
1.1 Required Tools
In addition to the conventional service tools which every service engineer has in his
toolbox, the following tools are required for service on the digitizer:
Tool Part Number* Purpose
Anti-static wrist strap CM+9 9999 0830 0 To avoid static discharges
on electronic components.
CR Screen Cleaner
(2 bottles)
10+9 9999 1197 0 To clean the Image Plates.
Lint free cloth Commercially available To clean the Image Plates.
Service key CM+9 0426 6309 0 To override the safety
switch.
Vacuum Cleaner Commercially available or
CM+9 9999 0895 0
(Vacuum cleaner
220/240V, 50Hz)
To clean the digitizer during
maintenance.
Dirt bags for vacuum
cleaner (10 x)
CM+9 9999 0896 0 To clean the digitizer during
maintenance. Fits to
Vacuum Cleaner
CM+9 9999 0895 0
* The last digit in the spare part number indicates the spare part revision at release of
this document. When ordering, the actual revision of the spare part is delivered.
