AGFA CR 30-X - Product Description; System Overview

DD+DIS172.06E
Installation Planning
123
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
Edition 1, Revision 5 CR 30-X Chapter 11 / 7
11-2010 Type 5175/100/105/110/120/125 Agfa Company Confidential
2 Product Description
This is the Installation Planning Document for the CR 30-X digitizers type 5175,
subtypes 100, 105, 110, 120 and 125.
Name of the digitizers:
 Subtypes 100, 105: CR 30-X
 Subtypes 110, 120, 125: Digitizer (ex factory no name on the covers)
All of the above mentioned subtypes are called "digitizer" in this document.
The differences between the different subtypes are described in section 9.
2.1 System Overview
The digitizer is part of the digitizer system, consisting of:
 Digitizer
 NX Workstation (Tower or laptop version)
 Cassette with Image Plate (IP)
Optional Components (not displayed)
 Printer (e.g. Drystar 5302)
 Additional Cassettes
 Uninterruptible Power Supply (UPS)
Digitizer
Cassette
NX Workstation
Laptop Version
517511ea.cdr
Digitizer
Cassette
NX Workstation
Tower Version
Figure 1
NOTE:
This document describes the installation planning of the digitizer.
For more information to the NX Workstation and optional printer refer to the
corresponding documents on MedNet, GSO Library.
