AGFA CR 30-X - Replacing the PMT with Light Collector; Replacing the Scan Rollers

DD+DIS150.06E
Repair and Service
Replacements / Repair Procedures
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
Edition 1, Revision 2 CR 30-X Chapter 3.5 / 90
03-2009 Type 5175 / 100/110 Agfa Company Confidential
3.5 Replacing the PMT with Light Collector
The replacement instructions for the PMT with Light Collector, spare part number*
CM+9 5175 9010 3, are enclosed to the spare part.
* The last digit in the spare part number indicates the spare part revision at release of this document.
When ordering, the actual revision of the spare part is delivered.
3.6 Replacing the Scan Rollers
REQUIRED SPARE PART*:
CM+9 5175 2650 1
* The last digit in the spare part number indicates the spare
part revision at release of this document. When ordering,
the actual revision of the spare part is delivered.
Figure 220
IMPORTANT:
Spare part CM+9 5175 2650 1 contains both upper scan rollers. It is recommended to
replace both scan rollers together.
REQUIRED TOOLS:
5 mm
3 mm
REQUIRED TIME:
45 min.
