AGFA CR 30-X - Recommended Tools

DD+DIS150
.06E
Repair and Service
Tools and auxiliary Means
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
1.2 Recommended Tools
Tool Part Number* Purpose
Canned air Commercially available To remove dust from modules after
disassembling from device.
Laser Beam
Detection Toolkit
CM+9 5175 2940 0 To check and adjust the laser beam
position at digitizers manufactured
between 10/2006 and 09/2009.
Magnifying glass 8x CM+9 9579 9904 0 To check image quality of films at the
lightbox.
Multimeter Commercially available
 To adjust the cassette edge
detection sensor.
 For troubleshooting
Service PC Commercially available
 To copy the digitizer software from
PC to CD ROM or USB stick.
 To evaluate the infocounter offline.
USB memory stick Commercially available To transfer data between the
processing station and the service PC.
* The last digit in the spare part number indicates the spare part revision at release of
this document. When ordering, the actual revision of the spare part is delivered.
NOTE:
As some screws are difficult to access, it is
recommended to have a 3 mm hex key with
ball-shaped head and a 6 mm magnetic hex
key in the tools assortment.
3 mm,
with ball-shaped head
6 mm (magnetic)
Figure 1
