4 Digitizer Dimensions
Dimensions in cm [inch].
Digitizer closed:
69.3 [27.3]
78.6 [30.9]
49.7 [19.6
]
517511aa.cdr
Figure 3
Digitizer opened:
69.3 [27.3]
100.6 [39.6]
49.7 [19.6]
517511ab.cdr
Figure 4
