DD+DIS150
.06E
Controls, Connections, and Setup Procedures
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
Edition 1, Revision 5 CR 30-X Chapter 1 / 16
11-2009 Type 5175 / 100/110 Agfa Company Confidential
6 Set Digitizer operational
The purpose of this section is to show the tasks that are required to set the digitizer
operational.
The following table lists these tasks.
Task Required
Time
Importance Task Code* Section
Check technical image
quality of the digitizer.
30 minutes mandatory INS
6.1
*Complete required time per Task Code to be entered in the Agfa repair report.
6.1 Checking the Technical Image Quality of the System
During the “Technical Image Quality Check” of the system a flatfield image is exposed
and checked at the lightbox. The procedure is divided in following steps:
# Task Section
1 Clean and check the image plate. 6.1.1
2 Erase the cassette. 6.1.2
3 Expose the cassette. 6.1.3
4 Scan the flatfield. 6.1.4
5 Check the image at the lightbox or viewing station. 6.1.5
6.1.1 Checking Image Plate before Exposure
(1) Select the largest available cassette. If possible, use a 35x43 cm Genrad
cassette.
If in size 35x43 cm only FLFS cassettes are available, use a FLFS cassette.
Distinction between Genrad and FLFS cassette see Figure 22 on page 21.
