DD+DIS171.06E
Maintenance
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
3.6 Cleaning of the Scan Line
IMPORTANT:
Only clean the scan line, if vertical stripes are visible in the image made under step
2.6, Checking current Image Quality.
Otherwise skip this step.
REQUIRED TOOLS:
Cleaning brush (attached to the digitizer "Cassette Unit")
(1) Clean the scan line by wiping with
the cleaning brush a few times over
the whole scan length.
The last movement must be
continuous from rear to front.
Figure 20
Edition 1, Revision 1 CR 30-X Chapter 9 / 19
01-2009 Type 5175 / 100/110 Agfa Company Confidential
